Güdel's new CoboMover™ linear track extends working range for cobots and small industrial robots to over 16 feet
Watch the latest track system in action on the auto assembly line.
Güdel is unveiling the Cobomover™, a 7th-axis linear track purpose-built for collaborative and lightweight robots.
Designed and manufactured in Switzerland, the Cobomover extends the working range of robots up to 5 meters (16.4ft), allowing them to operate multiple workstations and perform a variety of tasks without manual repositioning.
"The Cobomover is more than just another linear axis -- it's a game changer," says Brenda Courim, Head of Sales for Güdel Inc. "It's designed to help integrators and end users get the most out of their cobot and lightweight robot investments, with the same quality, repeatability, and ease of use to which Güdel's customers have become accustomed."
The CoboMover is compatible with over 60 cobots and small traditional robots. It offers mounting positions at 0° and 180°. The maximum payload, including robot weight, is 78 kg (172 lbs). Its drive system utilizes a toothed belt and Güdel's HPG045 angular gearbox. Available stroke lengths include 1000, 2000, 3000, 4000, and 5000 mm. The CoboMover has a maximum speed of 2 m/s and a maximum acceleration of 2 m/s², providing a repeatability of ± 0.05 mm.
Gliding on a cushion of air
With its reputation for robust track systems, heavy-payload gantries, and high-precision motion components, Güdel continues to expand its footprint by helping automation integrators solve real-world challenges.
A recent example of this to be showcased at Automate, is a modular track system fitted with air bearings. Using just 5 psi, the air bearing solution is able to levitate the TMF-4B track -- weighing 3,800 lbs -- half an inch above ground, enabling it to easily float into and out of position on a cushion of air. The solution was initially developed for aircraft painting applications, eliminating the need for cranes, high-payload forklifts or embedded rails.
Want more information/Watch in action? Click below.
